Cảm biến đo nồng oxy ITG Medical Oxygen Sensor M-04

• Brand: German ITG

Oxygen sensor (O2 medical type) M-04
Measuring range: 0-100%
Working life: 6 years in air
Output: 13 to 17 mV
Resolution: 0.1%
Temperature range: 0℃ to 40℃
Pressure range: 750 to 1250 hPa
Response time (T 90) : < 12S
Humidity range: 0-100 %RH (anti-high humidity)
Zero point output (100% N2, 20°C): < 0.2 mV
Maximum zero point drift (20°C to 40°C): 1%
long-term Drift: <1% /
Recommended load value        per month : =10KΩ
Linearity output: 2%
Repeatability: 1%
Storage life: 6 months (in container)
Interface: 3 pin sockets , with temperature compensation;
